LT3434IFE

LT3434IFE, 3A, 200kHz step-down switching regulator, TSSOP, 100uA, 35V

Rated 5 Rating 5 | reviews | Write a review

Price:: US $7.50~8.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
50 ~ 200 :	8.00 / Piece
200 ~ 1000 :	7.50 / Piece

PartNumber:: LT3434IFE

Brand:: Linear Technology - Linear | Pack: TSSOP | D/C: 12+

Availability:: Supply Ability: 1000/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Mr. JASON LU's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-07-01

From Other Seller

Part Number:LT3434IFE
US $7.50 - 8.00
Quantity:

piece

Product Summary

The LT3434IFE is a 200kHz monolithic buck switching regulator that accepts input voltages up to 60V. A high efficiency 3A, 0.1 Ω switch is included on the die along with all the necessary oscillator, control and logic circuitry. Current mode topology is used for fast transient response and good loop stability. Innovative design techniques integrated in a new high voltage process achieve high efficiency over a wide input range. Efficiency is maintained over a wide output current range by employing Burst Mode operation at low currents, utilizing the output to bias the internal circuitry, and by using a supply boost capacitor to fully saturate the power switch.

Parametrics

LT3434IFE absolute maximum ratings:(1)boost pin above SW: 35V; (2)boost pin voltage: 68V; (3)storage temperature range: –65°C to 150°C; (4)lead temperature (soldering, 10 sec): 300°C.

Features

LT3434IFE features: (1)wide input range: 3.3V to 60V; (2)3A peak switch current; (3)burst mode operation: 100μA quiescent current; (4)low shutdown current: IQ < 1μA; (5)power good flag with programmable threshold; (6)load dump protection to 60V; (7)200kHz switching frequency; (8)saturating switch design: 0.1Ω; (9)peak switch current maintained over; (10)full duty cycle range; (11)1.25V feedback reference voltage; (12)easily synchronizable; (13)soft-start capability; (14)small 16-pin thermally enhanced TSSOP package.
