Product Summary

The W9425G6JH-5 is a CMOS Double Data Rate synchronous dynamic random access memory (DDR SDRAM), organized as 4,194,304 words×4 banks×16 bits. W9425G6JH delivers a data bandwidth of up to 500M words per second (-4). To fully comply with the personal computer industrial standard, W9425G6JH-5 is sorted into the following speed grades: -4, -5 and -5I. The -4 is compliant to the DDR500/CL3 and CL4 specification. The -5/-5I is compliant to the DDR400/CL3 specification (the -5I grade which is guaranteed to support -40°C ~ 85°C).

Parametrics

W9425G6JH-5 absolute maximum ratings: (1)Input/Output Voltage: -0.5 ~ VDDQ + 0.5 V ; (2)Power Supply Voltage: -1 ~ 3.6 V; (3)Operating Temperature (-4/-5): 0~70°C; (4)Operating Temperature (-5I): -40~ 85°C; (5)Storage Temperature: -55 ~ 150°C; (6)Soldering Temperature (10s): 260°C; (7)Power Dissipation: 1 W; (8)Short Circuit Output Current: 50mA.

Features

W9425G6JH-5 features: (1)2.5V ±0.2V Power Supply for DDR400 ; (2)2.4V~2.7V Power Supply for DDR500 ; (3)Up to 250 MHz Clock Frequency ; (4)Double Data Rate architecture; two data transfers per clock cycle ; (5)Differential clock inputs; (6)DQS is edge-aligned with data for Read; center-aligned with data for Write ; (7)CAS Latency: 2, 2.5, 3 and 4 ; (8)Burst Length: 2, 4 and 8 ; (9)Auto Refresh and Self Refresh ; (10)Precharged Power Down and Active Power Down ; (11)Write Data Mask ; (12)Write Latency = 1 ; (13)7.8μS refresh interval (8K/64 mS refresh) ; (14)Maximum burst refresh cycle: 8 ; (15)Interface: SSTL_2 ; (16)Packaged in TSOP II 66-pin, using Lead free materials with RoHS compliant.

Diagrams

W9425G6JH-5 pin configuration

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
W9425G6JH-5I
W9425G6JH-5I


IC DDR SDRAM 256MBIT 66TSOPII

Data Sheet

0-1: $1.66
1-10: $1.49
10-25: $1.47
25-50: $1.46
50-100: $1.31
100-250: $1.26
250-500: $1.26
500-1000: $1.17
1000-2500: $1.15
Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
W9425G6EH-5
W9425G6EH-5


IC DDR-400 SDRAM 256MB 66TSSOPII

Data Sheet

Negotiable
W9425G6JH-5I
W9425G6JH-5I


IC DDR SDRAM 256MBIT 66TSOPII

Data Sheet

0-1: $1.66
1-10: $1.49
10-25: $1.47
25-50: $1.46
50-100: $1.31
100-250: $1.26
250-500: $1.26
500-1000: $1.17
1000-2500: $1.15
W942516CH
W942516CH

Other


Data Sheet

Negotiable
W942516BH
W942516BH

Other


Data Sheet

Negotiable
W942516AH
W942516AH

Other


Data Sheet

Negotiable
W942508CH
W942508CH

Other


Data Sheet

Negotiable
