Product Summary

The 52559-1672 is a FFC / FPC connector from Molex.

Features

52559-1672 features: (1)Product Family: FFC/FPC Connector; (2)Series: 52559; (3)Circuits (Loaded): 16; (4)Durability (mating cycles max): 20; (5)Entry Angle: Vertical; (6)Flammability: 94V-0; (7)Mated Height: 3.90mm (.154"); (8)Material - Metal: Phosphor Bronze; (9)Material - Plating: Mating Tin-Bismuth; (10)Material - Resin: Nylon; (11)Number of Rows: 1; (12)Orientation: Vertical; (13)PCB Locator: No; (14)PCB Retention: Yes; (15)Packaging Type: Embossed Tape on Reel; (16)Pitch - Mating Interface 0.50mm (.020"); (17)Polarized to PCB: No; (18)Stackable: No; (19)Temperature Range Operating: -40℃ to +85℃; (20)Termination Interface: Style Surface Mount; (21)Wire/Cable Type: FFC/FPC; (22)Current Maximum per Contact: 0.5A; (23)Voltage Maximum: 50V.

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
52559-1672
52559-1672

Molex

FFC / FPC Connectors VERTICAL SMT ZIF 16P FFC/FPC

Data Sheet

Negotiable
