Product Summary

The UCC2804D is a low-power bicmos current-mode PWM. The UCC2804D family of high-speed, low-power integrated circuits contain all of the control and drive components required for off-line and DC-to-DC fixed frequency current-mode switching power supplies with minimal parts count.These devices have the same pin configuration as the UC1842/3/4/5 family, and also offer the added features of internal full-cycle soft start and internal leading-edge blanking of the current-sense input.

Parametrics

UCC2804D absolute maximum ratings: (1)VCC Voltage: 12.0V; (2)VCC Current: 30.0mA; (3)OUT Current: ±1.0A; (4)OUT Energy (Capacitive Load): 20.0μJ; (5)Analog Inputs (FB, CS):–0.3V to 6.3V; (6)Power Dissipation at TA < +25°C (N or J Package): 1.0W; (7)Power Dissipation at TA < +25°C(D Package): 0.65W; (8)Power Dissipation at TA < +25°C (L Package): 1.375W; (9)Storage Temperature Range: –65°C to +150°C; (10)Lead Temperature (Soldering, 10 Seconds): +300°C.

Features

UCC2804D features: (1)100μA Typical Starting Supply Current; (2)500μA Typical Operating SupplyCurrent; (3)Operation to 1MHz; (4)Internal Soft Start; (5)Internal Fault Soft Start; (6)Internal Leading-Edge Blanking of the Current Sense Signal; (7)1 Amp Totem-Pole Output; (8)70ns Typical Response from Current-Sense to Gate Drive Output; (9)1.5% Tolerance Voltage Reference; (10)Same Pinout as UC3842 and UC3842A.

Diagrams

UCC2804D block diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
UCC2804D
UCC2804D

Texas Instruments

Current Mode PWM Controllers Low-Power BiCMOS Current-Mode PWM

Data Sheet

0-1: $2.04
1-25: $1.87
25-100: $1.49
100-250: $1.31
UCC2804D/81221
UCC2804D/81221

Texas Instruments

Current Mode PWM Controllers Lo-Pwr BiCMOS Crnt Mode PWM

Data Sheet

Negotiable
UCC2804DG4
UCC2804DG4

Texas Instruments

Current Mode PWM Controllers Low-Power BiCMOS Current-Mode PWM

Data Sheet

0-1: $2.04
1-25: $1.72
25-100: $1.49
100-250: $1.31
UCC2804DTR
UCC2804DTR

Texas Instruments

Current Mode PWM Controllers Low-Power BiCMOS Current-Mode PWM

Data Sheet

0-1860: $0.97
1860-2000: $0.94
2000-2500: $0.94
2500-5000: $0.90
UCC2804DR81221G4
UCC2804DR81221G4

Texas Instruments

Current Mode PWM Controllers Lo-Pwr BiCMOS Crnt Mode PWM

Data Sheet

Negotiable
UCC2804D/81221G4
UCC2804D/81221G4

Texas Instruments

Current Mode PWM Controllers Lo-Pwr BiCMOS Crnt Mode PWM

Data Sheet

Negotiable
UCC2804DTRG4
UCC2804DTRG4

Texas Instruments

Current Mode PWM Controllers Low-Power BiCMOS Current-Mode PWM

Data Sheet

0-1860: $0.97
1860-2000: $0.94
2000-2500: $0.94
2500-5000: $0.90
UCC2804DTR/81221
UCC2804DTR/81221

Texas Instruments

Current Mode PWM Controllers Lo-Pwr BiCMOS Crnt Mode PWM

Data Sheet

Negotiable
