Product Summary

The TLV274ID is a 550-UA/CH 3-MHZ rail to rail output operational amplifier. The TLV274ID takes the minimum operating supply voltage down to 2.7 V over the extended industrial temperature range while adding the rail-to-rail output swing feature. This makes it an ideal alternative to the TLV274ID family for applications where rail-to-rail output swings are essential. The TLV27x also provides 3-MHz bandwidth from only 550 μA.

Parametrics

TLV274ID absolute maximum ratings: (1)Supply voltage, VDD: 16.5 V; (2)Differential input voltage, VID: ±VDD; (3)Input voltage range, VI: -0.2 V to VDD + 0.2 V; (4)Input current range, II: ±10 mA; (5)Output current range, IO: ±100 mA; (6)Continuous total power dissipation: See Dissipation Rating Table; (7)Maximum junction temperature, TJ: 150°C; (8)Storage temperature range, Tstg: -65°C to 150°C; (9)Lead temperature 1,6 mm (1/16 inch) from case for 10 seconds: 260°C.

Features

TLV274ID features: (1)Rail-To-Rail Output; (2)Wide Bandwidth 3 MHz; (3)High Slew Rate 2.4 V/μs; (4)Supply Voltage Range: 2.7 V to 16 V; (5)Supply Current 550 μA/Channel; (6)Input Bias Current 1 pA.

Diagrams

TLV274ID package dimensions

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
TLV274ID
TLV274ID
Texas Instruments
Operational Amplifiers - Op Amps 550-uA/Ch 3-MHz R-to-R Otpt Oper Amp
Data Sheet
0-1: $0.92
1-25: $0.81
25-100: $0.64
100-250: $0.58
TLV274IDG4
TLV274IDG4
Texas Instruments
Operational Amplifiers - Op Amps 550-uA/Ch 3-MHz R-to-R Otpt Oper Amp
Data Sheet
0-1: $0.84
1-25: $0.68
25-100: $0.61
100-250: $0.56
TLV274IDR
TLV274IDR
Texas Instruments
Operational Amplifiers - Op Amps Quad 3MHz R/R
Data Sheet
0-1: $0.80
1-25: $0.63
25-100: $0.57
100-250: $0.50
TLV274IDRG4
TLV274IDRG4
Texas Instruments
Operational Amplifiers - Op Amps 550-uA/Ch 3-MHz R-to-R Otpt Oper Amp
Data Sheet
0-1730: $0.35
1730-2000: $0.33
2000-2500: $0.33
2500-5000: $0.32
