Product Summary

The BC807-16 is a PNP general purpose transistor. It is in a SOT23 plastic package. The device is designed for general purpose switching and amplification.

Parametrics

BC807-16 absolute maximum ratings: (1)VCBO collector-base voltage: max=-50 V; (2)VCEO collector-emitter voltage: max=-45 V; (3)VEBO emitter-base voltage: max=-5 V; (4)IC collector current (DC): max=-500 mA; (5)ICM peak collector current: max=-1 A; (6)IBM peak base current: max=-200 mA; (7)Ptot total power dissipation Tamb: max=250 mW; (8)Tstg storage temperature: min=-65℃, max=+150 ℃; (9)Tj junction temperature: max=150 ℃; (10)Tamb operating ambient temperature: min=-65℃, max=+150 ℃.

Features

BC807-16 features: (1)High current (max. 500 mA); (2)Low voltage (max. 45 V).

Diagrams

BC807-16 simplified outline

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
BC807-16
BC807-16

Taiwan Semiconductor

Transistors Bipolar (BJT) Transistor 300mW

Data Sheet

0-3000: $0.02
3000-6000: $0.02
BC807-16 /T3
BC807-16 /T3

NXP Semiconductors

Transistors Bipolar (BJT) TRANS GP TAPE-13

Data Sheet

Negotiable
BC807-16 T/R
BC807-16 T/R

NXP Semiconductors

Transistors Bipolar (BJT) TRANS GP TAPE-7

Data Sheet

Negotiable
BC807-16,215
BC807-16,215

NXP Semiconductors

Transistors Bipolar (BJT) TRANS GP TAPE-7

Data Sheet

0-1: $0.03
1-25: $0.01
25-100: $0.01
100-250: $0.01
BC807-16,235
BC807-16,235

NXP Semiconductors

Transistors Bipolar (BJT) TRANS GP TAPE-13

Data Sheet

0-1: $0.08
1-25: $0.07
25-100: $0.05
100-250: $0.03
BC807-16-7
BC807-16-7

Diodes Inc.

Transistors Bipolar (BJT) PNP BIPOLAR

Data Sheet

Negotiable
BC807-16-7-F
BC807-16-7-F

Diodes Inc.

Transistors Bipolar (BJT) PNP BIPOLAR

Data Sheet

0-1: $0.13
1-10: $0.11
10-100: $0.06
100-250: $0.04
BC807-16LT1G
BC807-16LT1G

ON Semiconductor

Transistors Bipolar (BJT) 500mA 50V PNP

Data Sheet

0-1: $0.10
1-25: $0.08
25-100: $0.06
100-500: $0.03
