Product Summary

The SM06B-SHLS-TF(LF)(SN) is a 1.0mm pitch/disconnectable crimp style connector.

Parametrics

SM06B-SHLS-TF(LF)(SN) specifications: (1)Current rating: 1.0A AC, DC; (2)Voltage rating: 50V AC, DC; (3)temperature range: -25℃ to +85℃; (4)Contact resistance: initial value/20m Ω max; (5)Insulation resistance: 100M Ω min; (6)Withstanding voltage: 5000V AC/minute; (7)Applicable wire: AWG#32 to #28.

Features

SM06B-SHLS-TF(LF)(SN) features: (1)Thin design; (2)Low insertion force; (3)Deformation preventive design.

Diagrams

SM06B-SHLS-TF(LF)(SN) dimensions
