Product Summary

The SBR130S3-7-F is a super barrier rectifier using state-of-the-art SBR IC processor technology.

Parametrics

SBR130S3-7-F absolute maximum ratings: (1)IF(AV), Rectangular Waveform: 1.0A; (2)VRRM: 30V; (3)VF@1A, TJ=75℃: 0.38V, typ; (4)TJ: -65 to 125℃ (operating/storage).

Features

SBR130S3-7-F features: (1)Low Forward Voltage Drop; (2)Low Reverse Leakage; (3)Reliable High Temperature Operation; (4)Super Barrier Design; (5)Softest, fast switching capability; (6)125℃ Operating Junction Temperature.

Diagrams

SBR130S3-7-F diagram
