Product Summary

The HT7133A-1 is a three-terminal low power high voltage regulator implemented in CMOS technology. It allows input voltages as high as 24V. The HT7133A-1 available with several fixed output voltages ranging from 2.1V to 5.0V. CMOS technology ensures low voltage drop and low quiescent current. Although designed primarily as fixed voltage regulator, the HT7133A-1 can be used with external components to obtain variable voltages and currents.

Parametrics

HT7133A-1 absolute maximum ratings: (1)Supply Voltage: -0.3V to 26V; (2)Power Consumption: 200mW; (3)Power Consumption: 150mW; (4)Storage Temperature: -50℃ to 125℃; (5)Operating Temperature: 0℃ to 70℃.

Features

HT7133A-1 features: (1)Low power consumption; (2)Low voltage drop; (3)Low temperature coefficient; (4)High input voltage (up to 24V); (5)TO-92 and SOT-89 packages.

Diagrams

HT7133A-1 Block Diagram
