Product Summary
The GL360 is a Φ3.2mm resin mold type infrered light emitting diode. It is suitable for floppy disk drives, optoelectronic switches and infrered applied systems.
Parametrics
GL360 absolute maximum ratings: (1)power dissipation, P: 90mW; (2)forward current, IF: 60mA; (3)peak forward curent, IFM: 1A; (4)reverse voltage, VR: 3V; (5)operating temeprature, Topr: -25 to 85℃; (6)storage temperature, Tstg: -40 to 85℃; (7)soldering temperature, Tsol: 260℃.
Features
GL360 features: (1)Φ3.2mm epoxy resin package; (2)intermediate beam angle; (3)high output.
Diagrams
 |
