Product Summary

The TPS51462RGER fully supports Intel system agent applications with integrated 2-bit VID function. The TPS51462RGER also features two switching frequency settings (700 kHz and 1 MHz), skip mode, pre-bias startup, programmable external capacitor soft-start time/voltage transition time, output discharge, internal VBST Switch, 2-V reference (±1%), power good and enable.

Parametrics

TPS51462RGER absolute maximum ratings: (1)Input voltage range: VIN, EN, MODE: –0.3 to 7.0; (2)Output voltage range: SW –2.0 to 7.0 V; (3)Electrostatic Discharge: Human Body Model (HBM)2000V; (4)Storage temperature: –55 to 150°C; (5)Junction temperature: –40 to 150°C.

Features

TPS51462RGER features: (1)Minimum External Parts Count; (2)Support all MLCC Output Capacitor and SP/POSCAP; (3)Auto Skip Mode; (4)Selectable 700-kHz and 1-MHz Frequency; (5)Small 4 mm × 4 mm, 24-Pin, QFN Package.

Diagrams

TPS51462RGER functional block diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
TPS51462RGER
TPS51462RGER

Texas Instruments

Switching Converters, Regulators & Controllers 3.3V/5Vin,DCAP Mode Sync SD Integ FET

Data Sheet

0-2395: $1.99
2395-3000: $1.97
