AT24C16B-PU

AT24C16B-PU, two-wire serial EEPROM, 6.25V, 5.0 mA

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.32~0.35 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
100 ~ 1000 :	0.35 / Piece
1000 ~ 5000 :	0.32 / Piece

PartNumber:: AT24C16B-PU

Brand:: ATMEL Corporation - ATMEL | Pack: | D/C: 09+

Availability:: Supply Ability: 10000/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Mr. JASON LU's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-06-29

From Other Seller

Part Number:AT24C16B-PU
US $0.32 - 0.35
Quantity:

piece

Product Summary

The AT24C16B-PU provides 16384 bits of serial electrically erasable and programmable read-only memory (EEPROM) organized as 2048 words of 8 bits each. The device is optimized for use in many industrial and commercial applications where low-power and low-voltage operation are essential. The AT24C16B is available in space-saving 8-lead PDIP, 8-lead JEDEC SOIC, 8-lead Ultra Thin Mini-MAP (MLP 2x3), 5-lead SOT23, 8-lead Ultra Lead Frame Land Grid Array (ULA), 8-lead TSSOP, and 8-ball dBGA2 packages and is accessed via a Two-wire serial interface. In addition, the AT24C16B-PU is available in 1.8V (1.8V to 5.5V) version.

Parametrics

AT24C16B-PU absolute maximum ratings: (1)Operating Temperature: –55°C to +125°C; (2)Storage Temperature: –65°C to +150°C; (3)Voltage on Any Pin with Respect to Ground: –1.0V to +7.0V; (4)Maximum Operating Voltage: 6.25V; (5)DC Output Current: 5.0 mA.

Features

AT24C16B-PU features: (1)Low-voltage and Standard-voltage Operation – 1.8 (Vcc= 1.8V to 5.5V); (2)Internally Organized 2048 x 8 (16K); (3)Two-wire Serial Interface; (4)Schmitt Trigger, Filtered Inputs for Noise Suppression; (5)Bidirectional Data Transfer Protocol; (6)Write Protect Pin for Hardware Data Protection; (7)16-byte Page (16K) Write Mode; (8)Partial Page Writes Allowed; (9)High-reliability.
