TPD1030F

2-IN-1 low-side switch, -0.3 to 7 V, 2.0 W, 1 A, Low Input Current, Low Leakage Current

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.90~1.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.90~1.00

PartNumber:: TPD1030F

Brand:: Toshiba Semiconductor - Toshiba | Pack: DIP | D/C: 08+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Mr. JASON LU's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-09-04

From Other Seller

Part Number:TPD1030F
US $0.90 - 1.00
EKZE250ELL152MK25S

US $0.10 - 1.00 / Piece
(0) Remove
ECA1HHG100

US $10.00 - 10.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The TPD1030F is a 2-IN-1 low-side switch for Motor, Solenoid and Lamp Drive. The TPD1030F has a vertical MOSFET output which can be directly driven from a CMOS or TTL logic circuit (e.g., an MPU). The IC is equipped with intelligent self-protection functions.

Parametrics

TPD1030F absolute maximum ratings: (1)Drain-source voltage VDS (DC): 40 V; (2)Drain current ID: Internally Limited; (3)Input voltage VIN: -0.3 to 7 V; (4)Power dissipation (t = 10 s) PD: 2.0 W; (5)Single pulse active clamp capability EAS: 10 mJ; (6)Active clamp current IAR: 1 A; (7)Repetitive active clamp capability EAR: 0.2 mJ; (8)Operating temperature Topr: -40 to 110 ℃; (9)Channel temperature Tch: 150 ℃; (10)Storage temperature Tstg: -55 to 150 ℃.

Features

TPD1030F features: (1)Can directly drive a power load from a CMOS or TTL logic; (2)Built-in protection circuits against overvoltage (active clamp), overtemperature (thermal shutdown), and overcurrent (current limiter).; (3)Low Drain-Source ON-resistance: RDS (ON) = 0.6 Ω(max) (@VIN = 5 V, ID = 0.5 A, Tch = 25℃); (4)Low Leakage Current: IDSS = 10 μA (max) (@VIN = 0 V, VDS = 30 V, Tch = 25℃); (5)Low Input Current: IIN = 300 μA (max) (@VIN = 5 V, Tch = 25℃); (6)8-pin SOP package with embossed-tape packing.
