Product Summary

The TLV70033DDCR is a 200-mA, low-IQ low-dropout regulator for portable devices. The TLV70033DDCR series of low-dropout (LDO) linear regulators are low quiescent current devices with excellent line and load transient performance. These LDOs are designed for power-sensitive applications. A precision bandgap and error amplifier provides overall 2% accuracy. Low output noise, very high power-supply rejection ratio (PSRR), and low dropout voltage make this series of devices ideal for most battery-operated handheld equipment. All device versions have thermal shutdown and current limit for safety.

Parametrics

TLV70033DDCR absolute maximum ratings: (1)Input voltage range, VIN: –0.3 to +6.0 V; (2)Enable voltage range, VEN: –0.3 to +6.0 V; (3)Output voltage range, VOUT: –0.3 to +6.0 V; (4)Maximum output current, IOUT: Internally limited; (5)Output short-circuit duration: Indefinite; (6)Operating junction temperature range, TJ: –55 to +150°C; (7)Storage temperature range, TSTG: –55 to +150°C.

Features

TLV70033DDCR features: (1)Very Low Dropout; (2)2% Accuracy; (3)Low IQ: 31 μA; (4)Available in Fixed-Output Voltages from 0.7 V to 4.8 V; (5)High PSRR: 68 dB at 1 kHz; (6)Stable with Effective Capacitance of 0.1 μF; (7)Thermal Shutdown and Overcurrent Protection; (8)Available in 1,5-mm × 1,5-mm SON-6, SOT23-5, and SC-70 packages.

Diagrams

TLV70033DDCR functional block diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
TLV70033DDCR
TLV70033DDCR

Texas Instruments

Low Dropout (LDO) Regulators 200mA Low IQ LDO Reg for Portables

Data Sheet

0-1: $0.31
1-25: $0.23
25-100: $0.19
100-250: $0.17
