RT8272GSP

RT8272GSP, DO-214AB, 3A, 24V, 1.2MHz step-down converter

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.24~0.26 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1000 ~ 2000 :	0.26 / Piece
2500 ~ 12500 :	0.24 / Piece

PartNumber:: RT8272GSP

Brand:: Richtek Technology Corporation - richtek | Pack: | D/C: 13+

Availability:: Supply Ability: 25000/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Mr. JASON LU's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-07-01

From Other Seller

Part Number:RT8272GSP
US $0.24 - 0.26
Quantity:

piece

Product Summary

The RT8272GSP is a high voltage buck converter that can support the input voltage range from 4.75V to 24V and the output current can be up to 3A. Current Mode operation provides fast transient response and eases loop stabilization. The chip provides protection functions such as cycle-bycycle current limiting and thermal shutdown protection. In shutdown mode, the regulator draws 25μA of supply current. The RT8272GSP is available in a SOP-8 (Exposed Pad) surface mount package.

Parametrics

RT8272GSP absolute maximum ratings: (1)Supply Voltage, VIN: -0.3V to 26V; (2)Switching Voltage, SW: -0.3V to (VIN + 0.3V); (3)BOOT Voltage: (VSW-0.3V) to (VSW + 6V); (4)All Other Pins Voltage: -0.3V to 6V; (5)Power Dissipation, PD @ TA = 25°C SOP-8 (Exposed Pad): 1.333W; (6)Package Thermal Resistance SOP-8 (Exposed Pad), θJA: 75°C/W; (7)Junction Temperature: 150°C; (8)Lead Temperature (Soldering, 10 sec.): 260°C; (9)Storage Temperature Range: -65°C to 150°C; (10)ESD Susceptibility (Note 3) HBM (Human Body Mode): 2kV; (11)MM (Machine Mode): 200V.
