Product Summary

The HCPL-0630-500E is a high CMR, high speed TTL compatible optocoupler. It combines a GaAsP light emitting diode and an integrated high gain photo detector. An enable input allows the detector to be strobed. The applications of the HCPL-0630-500E include: (1)Isolated Line Receiver; (2)Computer-Peripheral Interfaces; (3)Microprocessor System Interfaces; (4)Digital Isolation for A/D, D/A Conversion; (5)Switching Power Supply; (6)Instrument Input/Output Isolation; (7)Ground Loop Elimination; (8)Pulse Transformer Replacement; (9)Power Transistor Isolation in Motor Drives; (10)Isolation of High Speed Logic Systems.

Parametrics

HCPL-0630-500E absolute maximum ratings: (1)Storage Temperature TS: min=-55℃, max=125℃; (2)Operating Temperature TA: min=-40℃, max=85℃; (3)Average Forward Input Current IF: max=20mA; (4)Reverse Input Voltage VR: max=5V; (5)Input Power Dissipation PI: max=40mW; (6)Supply Voltage VCC: max=7V; (7)Enable Input Current IE: max=5mA; (8)Output Collector Current IO: max=50mA; (9)Output Collector Voltage VO: max=7V.

Features

HCPL-0630-500E features: (1)5 kV/μs Minimum Common Mode Rejection (CMR) at VCM = 50 V for HCPL-X601/X631, HCNW2601 and 10 kV/μs Minimum CMR at VCM = 1000 V for HCPLX611/X661, HCNW2611; (2)?High Speed: 10 MBd Typical; (3)LSTTL/TTL Compatible; (4)Low Input Current Capability: 5 mA; (5)Guaranteed ac and dc Performance over Temperature: -40℃ to +85℃; (6)Available in 8-Pin DIP, SOIC-8, Widebody Packages; (9)Strobable Output (Single Channel Products Only).

Diagrams

HCPL-0630-500E functional diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
HCPL-0630-500E
HCPL-0630-500E

Avago Technologies

High Speed Optocouplers 10MBd 2Ch 5mA

Data Sheet

0-1: $3.04
1-25: $2.48
25-100: $2.21
100-250: $1.99
Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
HCPL-0501-500E
HCPL-0501-500E

Avago Technologies

High Speed Optocouplers 1MBd 1Ch 16mA

Data Sheet

0-1: $1.08
1-25: $0.81
25-100: $0.72
100-250: $0.65
