Product Summary

Circuits (Loaded) 40
Color - Resin Natural
Durability (mating cycles max) 30
Glow-Wire Compliant No
Mated Height (in) 0.177 In, 0.222 In, 0.256 In
Mated Height (mm) 4.50 mm, 5.65 mm, 7.00 mm
Material - Metal Phosphor Bronze
Material - Plating Mating Tin
Material - Plating Termination Tin
Material - Resin High Temperature Thermoplastic
Number of Rows 2
Orientation Vertical
PCB Locator No
PCB Retention None
Packaging Type Embossed Tape on Reel
Pitch - Mating Interface (in) 0.031 In
Pitch - Mating Interface (mm) 0.80 mm
Plating min: Mating (μin) 40
Plating min: Mating (μm) 1
Plating min: Termination (μin) 40
Plating min: Termination (μm) 1
Polarized to PCB No
Surface Mount Compatible (SMC) N/A
Temperature Range - Operating -20°C to +105°C
Termination Interface: Style Surface Mount
Electrical
Current - Maximum per Contact 0.5A
Voltage - Maximum 50V

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
52465-4071
52465-4071

Molex

Board to Board / Mezzanine Connectors 0.8 BtB Hsg Assy SMT SMT 40Ckt EmbsTp Pkg

Data Sheet

0-1: $5.17
1-10: $4.66
10-100: $3.67
100-500: $3.03
